48V 5Kwh LiFePO4 Battery Support Max 4 Parallels 5 Years Warranty
5Kwh LiFePO4 Battery details :
1. Diameter*Height : 482*400*177mm
2. Nominal Voltage : 51.2V
3. Nominal Capacity : 5kwh
4. Cycle life : 8000 cycles
5. Standard charging ways : CC / CV
6. With or without 5kw Off-Grid Inverter by your choose
7. BMS inside ,CE , UL , UN38.3 , MSDS compliant
8. Warrenty: 5 Years
5Kwh LiFePO4 Battery Specifications :
Model No | EA4850 | EA48100 | EA48150 | EA48200 | EA48250 |
Voltage | 48 V | 48 V | 48 V | 48 V | 48 V |
Capacity | 50Ah | 100Ah | 150Ah | 200Ah | 250Ah |
Energy | 2.4KWH | 5.12KWH | 7.68KWH | 10.24KWH | 12.80KWH |
Operation voltage | 35.25-54.75 Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc | 37.6-58.4Vdc |
Max.charging voltage | 54.75Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc | 58.4 Vdc |
Max.charging and discharging current | 50A | 100A | 100A | 100A | 100A |
Max Power | 2400W | 5120W | 7680W | 10240W | 12800W |
Life time(25°C) | |
Life cycles(80% DOD, 25°C) | |
Storage time / temperature | 5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C |
Operation temperature | -20°C to 60°C @60+/-25% Relative Humidity |
Storage temperature | 0°C to 45°C @60+/-25% Relative Humidity |
Lithium Battery Standard | UL1642, IEC62619, UN38.3, ROHS,CE-EMC |
Enclosure protection rating | |
Dimensions(L×W×H)mm | | | | | |
Weight | | | | | |
5Kwh LiFePO4 Battery Description :
EA48100 is a high-voltage battery storage system based on
lithium-iron phosphate battery, which is one of the new energy
storage products developed and produced by EA Energy. is modular in
4.8 kWh increments, providing a capacity range of 4.8kwh-38.4kWh
per stack It can be used to support relable power for various types
of equipment and systems. It is especially suitable for those
application scenes which required high power output, limited
installation space, restricted load-bearing and long cycle life.
Monitor Digital Display
Battery is with digital display which allow users to monitor
voltage of each serial of cells, battery’s rated voltage and
capacity, temperatures and BMS parameters etc.
The system has a built-in BMS battery management system, which can
manage and monitor cell’s information including voltage, current
and temperature. What’s more, the BMS can help extend the cycle
life by balancing cells during charging and discharging. Save
installation time and labor. WiFi App Management Optional. Longer
Cycle Life:6000 Cycle Life @80%DOD.
Easy to move with wheels.Compact and portable design,indoor and
outdoor workable. Double input:Solar energy charging adn Utility
Grid charging.
Support max 4 parallels
If without master control, it support max 4 parallels for highest
20.48Kwh battery system; If with standard master controls,
it can be paralleled and serialed with more batteries.
24 hours power storage , smart BMS home energy storage system ,
providing DC power services suitable
for all scenarios , special pefect for home , microgrid or
commercial school use .
5Kwh LiFePO4 Battery Details :
5Kwh LiFePO4 Battery Applications :
The battery storage system can be applicated with solar panels
,mountain communication base station ,communication base station
energy storage ,backup power , outdoor micro station , wind power
system etc...
