3.2V 4000mAh 26700 LiFePO4 Battery Cells For Solar Power Backup
System
3.2v 4000mAh Li Iron Battery 26700 LiFePO4 Battery Cells For Solar
Panels , Solar Power , Backup System
LiFePO4 Battery Cell Quick details:
1. Diameter*Height : 26*70mm (LiFePO4 26700 size)
2. Nominal Voltage : 3.2V
3. Nominal Capacity : 4000 mAh 12.8Wh
4. Cycle life : 5000 cycles
5. Standard charging ways : CC / CV
6. Li-ion / Lithium Ion LiFePO4 battery cell
7. CE , UL , UN38.3 , MSDS compliant
26700 Battery Cell Description:
EA Energy LiFePO4 battery use Automotive Grade LiFePO4 Cells with
higher energy density, more stable performance and greater power.
Unlike the Lead Acid batteries, lithium iron phosphate lifepo4
battery has higher energy density and has longer service life
Smart Built-in BMS Protection:
BMS (Battery Management System) is like human brain to balance the
voltage between battery cells in order to protect against
over-discharge, short circuit, overcharge, overheating and
overloading.
The battery uses imported original big brand ion batteries, with a
small internal resistance, big capacity, cycle times and more, no
memory effect, etc; internal circuit for multiple protection
design, can prevent over charge, over discharge, over current;
production process quality inspection and monitoring the use of
computers to ensure superior battery performance.
the voltage is stable, far superior to ternary polymer batteries
and lead acid batteries.
90% of the energy of the iron phosphate battery is concentrated in
a small area of 3-3.2v, and the discharge characteristics are very
stable.
Under normal condition use, li ion deep cycle battery provides the
service life of 3000 - 7000 cycles while only 300 - 500 cycles for
Lead Acid battery
lithium iron phosphate is strictly Safety tests do
All battery are UL listed to ensure quality
LiFePO4 deep cycle battery can be used in many places, such as
travel trailer,boat,car audio,fish finder,camper van,solar
panels,solar power, backup system,server rack,off grid application.
We can also customize any size and function you need.Such as
12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah,
400ah, 800ah etc..
LiFePO4 Battery Cell Specifications :
| NO | Items | Specification | Remarks |
| 1 | Nominal Capacity | 4000mAh | 0.2C 5A Discharge |
| 0.2C 5A Discharge |
| 2 | Nominal Voltage/shipping voltage | 3.2V/3.15-3.25V | Voltage |
| 3 | Discharge Cut-off Voltage | 2.0V | 0.2C 5A Discharge |
| 0.2C 5A Discharge |
| 4 | Charge Limited Voltage | 3.65±0.03V | 0℃～45℃ |
| 5 | Standard Charge Current | 1C A | 0℃～45℃ |
| 6 | Standard Discharge Current | 1C A | -20℃~ +60℃ |
| 7 | Rapid Charge Current | 1C A | 10℃～45℃ |
| 8 | Rapid Discharge Current | 1C A | -20℃~ +60℃ |
| 9 | Max. Charge Current | 3C A | |
| Max Pulse Current | 3C | |
| 10 | Internal Impedance | ≤1mΩ | AC 1kHz condition |
| At AC 1kHz |
| 11 | Weight | About 85.0g | Weight 85±2g |
|
| 12 | Storage Temperature Range | ≤1 month | -20~ 45℃ | Factory Voltage 3.3~3.45V |
| ≤3 months | 0℃~ +30℃ | Ex-factory Voltage3.3~3.45V |
| ≤12 months | 20±5℃ | |
LiFePO4 Battery Cell Other 26650 26700 cells :
Part No |
Nominal Voltage |
Rated Capacity |
Internal Resistance |
Discharge Rate | Dimension(mm) |
Weight(g) |
| Diameter | Height |
| EA-LFP26650-3.2V-2500mAh | 3.2V | 2500mAh | <10 m Ω | 20C | 26.3±0.1 | 65.2±0.2 | 87 |
| EA-LFP26650-3.2V-3000mAh | 3.2V | 3000mAh | <10 m Ω | 10C | 26.3±0.1 | 65.2±0.2 | 85 |
| EA-LFP26650-3.2V-3200mAh | 3.2V | 3200mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 85 |
| EA-LFP26650-3.2V-3300mAh | 3.2V | 3300mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 85 |
| EA-LFP26650-3.2V-3400mAh | 3.2V | 3400mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 85 |
| EA-LFP26650-3.2V-3600mAh | 3.2V | 3600mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 85 |
| EA-LFP26650-3.2V-3800mAh | 3.2V | 3800mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 87 |
| EA-LFP26650-3.2V-4000mAh | 3.2V | 4000mAh | <25 m Ω | 3C | 26.3±0.1 | 65.2±0.2 | 88 |
LiFePO4 Battery Cell Products Details :
LiFePO4 Battery Cell Applications:
26650 Battery cells Perfect for Wireless camera, surveillance cameras, wireless infrared detector,
car LCD TV, portable DVD, personal treatment system, PDA personal
data assistant, personal communications systems, walkie-talkies,
digital cameras, camcorders, video cameras, Bluetooth devices, CD
players, MD players, MP3 players, smart cards, aviation model LED
lights and other fields can be used with LiFePO4 batteries.
