7000 Cycles 12V 120Ah LiFePO4 Battery Pack Low Self Discharge Rate
12V 120Ah Deep Cycle LiFePO4 Battery Lithium Batteries With
Built-In 100AH BMS And 7000+ Cycles
Deep Cycle LiFePO4 Battery details:
1. Diameter*Height: 329*172*220mm
2. Nominal Voltage: 12.8V
3. Nominal Capacity: 120A 1536Wh
4. Cycle life: 4000 cycles
5. Standard charging ways: CC / CV
6. Li-ion / Lithium Ion rechargeable LiFePO4 battery
7. CE , UL ,UN38.3 , MSDS compliant
Deep Cycle LiFePO4 Battery Description:
EA ENERGY 12.8V 120Ah LiFePO4 battery can be connected in parallel
& in series for larger capacity. Allow being extended up to 4S or
4P to get Max 480Ah capacity or Max 48V(51.2V) voltage. Widely used
in most areas such as RV, Solar, Household Battery, Off-Grid and
Electric Scooter, Electric Handicap , home backup power, RV,
camping, sailboat, etc. and so on.
LiFePO4 battery can be recycled up to 4000~8000 times with 10 years
of service life. The Grade A LiFePO4 Cells is with higher energy
density and highest-level safety based on UL certificates for the
cells. With the advantages of 1/3 lightweight, low self-discharge
rate, and 3 times usable energy, EA ENERGY LiFePO4 battery can
perfectly replace the lead-acid battery.
100% safe, nontoxic, renewable energy. LiFepo4 battery will not
burn when overcharged, over discharged, over current or short
circuit, and can withstand high temperatures without decomposition.
Smart BMS inside can handle cell balancing, low & high voltage
cutoff, short circuit protection and temperature protection.
Without memory effect, no matter what state the battery is, it can
be used as soon as it is charged.
Our 12.8V 120Ah Lithium battery builds in 100A BMS, which can
prevent the LifePO4 battery from the most common issue causing of
battery failure, such as overcharge, over-discharge, over-current
and short circuit. Our 12.8V 120Ah LiFePO4 battery only needs a
5-hour fast charging time when charging by 14.6V 25A LiFePO4
battery charger, saving 50% time in charging compared with
lead-acid battery which needs 10 hours charging time to around 70%
capacity.
EA ENERGY 120Ah LiFePO4 battery built-in 100A BMS, which supports
120A max. continuous charge/discharge current, 1536W max. Load
power and 3072Wh max. energy. Equipped with exceptional quality
100A BMS can also limit the continuous charge/discharge current,
our 240Ah LiFePO4 battery can better protect the battery
performance and prolong the cycle times. We do 100% testing for all
120ah batteries before shipping them to you.
EA ENERGY 12.8V 120Ah LiFePO4 battery provides 4000+ cycles times
and 1536Wh energy, which means our 100Ah battery produces 6140kWh
(1536Wh*4000 cycles times=6140kWh) in its 10-year lifespan, which
means you will save 1/2 of power fees compare with using the
utility power. Our LiFePO4 batteries are widely used for solar
system, RV trip and outdoors activities, you could enjoy
self-reliant colorful life when using the battery in solar source.
EA ENERGY provides 5-year warranty for 12.8V 120Ah LiFePO4 battery.
Deep Cycle LiFePO4 Battery Specifications:
Electrical Characteristics | Nominal Voltage | 12.8V |
| Nominal Capacity | 120Ah@0.2C |
| Energy | 1536Wh |
| Internal Resistance | 45≤mΩ |
| Cycle Life | 7000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity |
| Self Discharge | ≤3.5% per month at 25℃ |
| Standard Charging | Max.Charging Voltage | 14.0~14.6V |
| Charging Mode | At 0℃~45℃ temperature, charged to 14.6V at a constant current of
0.2C5A, andthen,changed continuously with constant voltage of 14.6V
until the current was notmore than 0.02C5A |
| Charging Current | 25A |
| Max.Charging Current | 60A |
| Standard Discharging | Discharging Current | 25A |
| Max. Continuous Current | 120A |
| Max.Pulse Current | 240A(<3S) |
| Discharging Cut-off Voltage | 10.0V |
| Operating Condition | Charge Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity |
| Storage Temperature | 0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity |
| Water Dust Resistance | IP55 |
| Structure | Cell & Format | IFR32700 |
| Casing | Plastic |
| Dimension(L*W*H*TH) | 329*172*243mm |
| Weight | Approx. 13Kg |
| Terminal | M8 |
Deep Cycle LiFePO4 Battery Products Details :
Deep Cycle LiFePO4 Battery Applications:
12V 120Ah LiFePO4 battery pack widely used in most areas such as
RV, Solar, Household Battery, Off-Grid and Electric Scooter,
Electric Handicap and so on. Note: The battery cannot be used as a
starting battery .
